Inline High Pressure Check Valve — CV
Hexagon-body inline check valve, BSP ports, 1/4" to 2", with 0.5/1 bar cracking pressure.
Western Hardware Mart, Kolkata supplies the Asian Hydraulic Inline High Pressure Check Valve — CV as part of our inline check valves range. Available in 8 sizes or variants (DN 6–50, max flow 15–430 l/min, weight 0.1–2.7 kg). Part numbers: CV G 1/4, CV G 3/8, CV G 1/2, CV G 3/4, CV G 1", CV G 1-1/4", CV G 1-1/2", CV G 2". Specifications include body Hexagon, material 1.0737 / 1.4749 and operating pressure PN500 (by size, 350–400 bar). Message us on WhatsApp or call +91 98746 36636 for price and availability.
- BodyHexagon
- Material1.0737 / 1.4749
- Sizes1/4" to 2"
- Operating pressurePN500 (by size, 350–400 bar)
Enquire about this product
Send us the product details and we’ll reply with availability and pricing.
Specifications
- Body
- Hexagon
- Material
- 1.0737 / 1.4749
- Sizes
- 1/4" to 2"
- Operating pressure
- PN500 (by size, 350–400 bar)
- Cracking pressure
- 0.5 / 1 bar
- Temperature range
- -10 °C to +100 °C depending on seal material
Sizes & variants
| Type | PN | DN | Max flow (l/min) | Weight (kg) |
|---|---|---|---|---|
| CV G 1/4 | 400 bar | 6 | 15 | 0.1 |
| CV G 3/8 | 400 bar | 10 | 30 | 0.18 |
| CV G 1/2 | 400 bar | 13 | 50 | 0.23 |
| CV G 3/4 | 400 bar | 20 | 90 | 0.45 |
| CV G 1" | 400 bar | 25 | 150 | 0.73 |
| CV G 1-1/4" | 350 bar | 32 | 200 | 1.49 |
| CV G 1-1/2" | 350 bar | 40 | 300 | 2 |
| CV G 2" | 350 bar | 50 | 430 | 2.7 |
Need a size that isn’t listed? Ask us — other configurations may be available on request.
