Chain & lever hoists
Heavy Duty Chain Pulley Block — T Series
T SeriesHeavy duty manual chain pulley block with Grade 80 alloy steel load chain, for general industrial lifting.
Chain Pulley Block — B Series
Compact, lightweight manual chain pulley block with Grade 80 alloy steel load chain for heavy duty industrial applications.
Western Hardware Mart, Kolkata supplies the Chain Pulley Block — B Series as part of our chain & lever hoists range. Available in 6 sizes or variants (capacity 1–20 t, test load 1.25–25 t, chain dia 6–10 mm). Part numbers: CBRL0103, CBRL0203, CBRL0303, CBRL0503, CBRL1003, CBRL2003. Specifications include chain diameter 6 – 10 mm and certification CE certified (as per manufacturer brochure). Message us on WhatsApp or call +91 98746 36636 for price and availability.
- Capacity range1 – 20 tonnes
- Chain diameter6 – 10 mm
- CertificationCE certified (as per manufacturer brochure)
Enquire about this product
Send us the product details and we’ll reply with availability and pricing.
Specifications
- Capacity range
- 1 – 20 tonnes
- Chain diameter
- 6 – 10 mm
- Certification
- CE certified (as per manufacturer brochure)
Sizes & variants
| Capacity (t) | Item Code | Test Load (t) | Chain Dia (mm) | Load Chain Falls | Weight (kg) |
|---|---|---|---|---|---|
| 1 | CBRL0103 | 1.25 | 6 | 1 | 6.14 |
| 2 | CBRL0203 | 2.5 | 8 | 1 | 10.7 |
| 3 | CBRL0303 | 3.75 | 8 | 2 | 13.1 |
| 5 | CBRL0503 | 6.25 | 10 | 2 | 23.9 |
| 10 | CBRL1003 | 12.5 | 10 | 4 | 47.24 |
| 20 | CBRL2003 | 25 | 10 | 8 | 89 |
Need a size that isn’t listed? Ask us — other configurations may be available on request.
Related products
Chain & lever hoists
Chain Pulley Block — Revolve Series
Revolve SeriesHand chain hoist with a 360° rotating hand chain guide that lets the operator work from various angles and stay out of the danger zone.
Chain & lever hoists
Ratchet Lever Hoist
