Slings, Chains & Rigging Hardware Lifting chain

G80 Alloy Steel Chain

Model / code: LCSL Series
Category: Slings, Chains & Rigging Hardware

Grade 80 alloy steel lifting chain, 6 mm to 32 mm, with working load limits as per EN 1677.

Western Hardware Mart, Kolkata supplies the G80 Alloy Steel Chain (LCSL Series) as part of our lifting chain range. Available in 15 sizes or variants (chain size 6–32 mm, capacity 1–31.5 t, weight 0.78–22.29 kg/m). Part numbers: LCSL0806, LCSL8063, LCSL0807, LCSL0808, LCSL0810, LCSL0811, LCSL0812, LCSL0814, LCSL0816, LCSL0818 and 5 more. Specifications include WLL reference EN 1677. Message us on WhatsApp or call +91 98746 36636 for price and availability.

Chain size6 – 32 mm
Capacity1 – 31.5 ton
WLL referenceEN 1677

Enquire about this product

Send us the product details and we’ll reply with availability and pricing.

Enquire on WhatsApp

Send an Email

+91 98746 36636 Request a formal quote

Specifications

Chain size: 6 – 32 mm
Capacity: 1 – 31.5 ton
WLL reference: EN 1677

Sizes & variants

Chain Size (mm)	Item Code	Capacity (t)	Weight (kg/m)
6	LCSL0806	1	0.78
6.3	LCSL8063	1.3	0.84
7.1	LCSL0807	1.5	1.1
8	LCSL0808	2	1.38
10	LCSL0810	3	2.15
11.2	LCSL0811	3.3	2.68
12	LCSL0812	5	3.00
14	LCSL0814	6.3	4.00
16	LCSL0816	8	5.30
18	LCSL0818	10	6.95
20	LCSL0820	12.5	8.6
22	LCSL0822	15	10.3
26	LCSL0826	21	14.5
28	LCSL0828	25	17.3
32	LCSL0832	31.5	22.29
